Klark Teknik DI 10A 1 channel Active Direct Box with Midas Transformer

Powerfully Pristine Audio

Boasting massive headroom, dynamic range, and sonic clarity, the Klark Teknik DI 10A has you covered. Experience the ultra-clean active circuitry powered by +48V phantom power. Perform with full confidence with the built-in 9-volt battery back up; even if you lose phantom power, you won’t lose the crisp clarity of your performance because this battery automatically kicks in when it’s needed. Sweetwater techs love the active circuitry that gives the DI 10A a high headroom and a wide dynamic range to effectively capture the instrument, sampler, or other balanced stereo source you’ve got plugged in. You can also take this active box with you anywhere: the rubber corner bumpers and thick, rugged aluminum housing give the DI 10A the ability to withstand the bumps and bruises of life on the road or in the studio. With time-trusted Midas transformers added, the DI 10A will provide you with reliable, crystalline audio every time you use it.

Features:

1. Powered by +48v console phantom power
2. High-quality Neutrik XLR and high impedance 1/4-inch TS connectors to maintain the highest signal integrity
3. Easily accommodates signal levels ranging from +10 to +50 dBu
4. Forget ground looping problems with the earth lift switch
5. Switchable input attenuator for signal levels from instruments to loudspeakers
6. 9V battery backup
7. Active DI Box for general purpose and multimedia applications
8. Custom-built Midas transformer for highest signal integrity
9. High headroom design offers superior sound quality
10. Powered from console +48 V phantom or internal battery (not included)
11. Automatic switchover to battery if phantom power fails
12. Matches the level and impedance with unity gain without loading the source
13. Switchable input attenuation for guitar, line and speaker levels
14. High quality Neutrik* XLR and high impedance 1/4” TRS connectors
15. Earth Lift switch eliminates ground loop problems
16. Fully transformer-isolated design ensures electrical separation
17. Ultra-low noise and ultra-linear system for highest signal integrity
18. Aluminium extrusion casing with protective rubber corners
19. Compact and rugged design
20. Designed and engineered in the U.K.
21.

• Type: Active
• Channels: 1
• Pads: -20dB, -40dB
• Ground Lift: Yes
• Inputs: 1 x 1/4″, 1 x XLR
• Outputs: 1 x XLR
• Other I/O: 1 x 1/4″ (thru)
• Power Source: 48V Phantom Power
• Height: 2.5″
• Depth: 4.7″
• Width: 4.6″
• Weight: 1.2 lbs/ 0.56 kg
