Markbass TA503 500W Bass Amp Head
Rp14.300.000
Stok 100
Stok 100
Pengiriman
Courier delivery
Our courier will deliver to the specified address
2-3 Days
From $20
DHL Courier delivery
DHL courier will deliver to the specified address
1-3 Days
From $40
Warranty 1 year
Free 30-Day returns
Description
The Markbass TA503 has a premium tube preamp that gives this bass amp head the advantage of tube warmth and analog clarity simultaneously. The TA503 bass head boasts a flexible EQ with 4-band semi-parametric tone control and Markbass’ signature VLE (Vintage Loudspeaker Emulator) and VPF (Variable Pre-shape Filter) filters.
Markbass gave the TA503 bass amplifier a Pre EQ/Post EQ switch to determine whether the output signal is affected by the EQ settings or not, as well as Send and Return Effect I/O to insure your main signal continues even if something along your effect chain breaks or runs out of batteries. An optional footswitch provides mute-to-tune and EQ bypass control.
Features
- Tube preamp analog bass head
- Provides 300W RMS at 8 ohms, 500W RMS at 4 ohms
- 1/4″ input jack works with active or passive basses
- Gain and Master volume controls
- Clip warning light
- Line out volume control knob
- EQ includes controls for Low, Mid Frequency Low, High Frequency Low, and High
- Mid Frequency High and Low level controls for deciding how much frequency area will be affected
- VLE (Vintage Loudspeaker Emulator) and VPF (Variable Pre-shape Filter) filters
- Neutrik Speakon Combo out jacks for use with 1/4″ or Speakon speaker cables
- Balanced XLR out
- Pre EQ/Post EQ switch to determine whether the output signal is effected by the EQ settings or not
- Ground lift switch to eliminate hum
- Tuner out sends unbalanced signal sent to a tuner, amp or recording equipment not needing a balanced signal
- Send and Return Effect ensures main signal continues even if something dies in your effects chain
- Dual-sided fiberglass PC boards with lined perforations for high-quality solder connections
- Surface-mount components are silicon-sealed to isolate vibrations
- Computer-grade pre-assembled ribbon connector cable harnesses and ribbons for noise-free operation
- Integrated threaded posts for easy assembly/disassembly and added durability
- Rigid 2mm thick aluminium chassis for a long-lasting finish
TA503 500W Bass Amp Head Specifications:
- Power
- Passive Input impedance: 500Kohm, max. voltage: 4 Vpp
- Effect return impedance: 500Kohm, max. voltage: 10 Vpp
- Active Input impedance: 500Kohm, max. voltage: 10 Vpp
- Output Power: 300W RMS at 8 ohms, 500W RMS at 4 ohms
- Voltage is factory preset for the U.S.
- Controls
- GAIN: —80dB to +35dB range
- LINE OUT: Level control on front panel
- PRE/POST EQ (for line out): Switch on rear panel
- GROUND LIFT: Switch on rear panel
- MASTER VOLUME
- FOOTSWITCH: Mute, EQ bypass
- Equalization
- LOW
- Center frequency: 40-300Hz; level ±16dB
- LOW-MID
- Semi-parametric: frequency 100—800Hz, level ±16dB
- HIGH-MID
- Semi-parametric: frequency 700Hz — 6kHz, level ±16dB
- HIGH
- Semi-parametric: 1.5-10kHz shelf; level ±16dB
- VPF (Variable Pre-shape Filter)
- Center frequency: 380Hz (cut)
- VLE (Vintage Loudspeaker Emulator)
- 250Hz — 20kHz cut
- Outputs
- EFFECT SEND
- Unbalanced, max. voltage 20 Vpp (pre-EQ)
- TUNER OUT
- Unbalanced, max. voltage 2 Vpp
- LINE OUT
- Balanced XLR, max. voltage 15 Vpp
- SPEAKER OUT
- Speakon, 1/4″
- Other
- Dimensions: 14.5″(W) x 3.39″(H) x 11.89″(D)
- 2U tall
- 19″(W) with rack ears
- Weight: 8.6lbs.
- Tubes: 1 x EECC81, 1 x ECC83 (JJ Electronic)
