Celestion NTR10-2520D 10″ Neodymium Midbass 8 Ohm
The neodymium NTR10-2520D 10″, from Celestion, utilizes a 2.5″ high-temperature, inside/outside, copper clad aluminum voice coil to effectively dissipate heat, and prohibit sensitivity loss through thermal compression. An intelligent heat management motor assembly and chassis enables reduced thermal compression. The M-roll cloth surround allows for progressive excursion control, generating a smooth frequency response.
Specifications
- Nominal Diameter………………………………………….10″
- Power Handling (RMS)…………………………………..250 Watts
- Power Handling (max)……………………………………500 Watts
- Impedance……………………………………………………8 ohms
- Frequency Response…………………………………….55 to 3,500 Hz
- Sensitivity…………………………………………………….96 dB 1W/1m
- Voice Coil Diameter……………………………………….2.5″
- Weight…………………………………………………………6 lbs.
Thiele-Small Parameters
- Resonant Frequency (Fs)………………………………………………56.7 HzDC
- Resistance (Re)……………………………………………………………6.11 ohms
- Voice Coil Inductance (Le)……………………………………………..0.55 mH
- Mechanical Q (Qms)……………………………………………………..2.76
- Electromagnetic Q (Qes)……………………………………………….0.41
- Total Q (Qts)………………………………………………………………..0.35
- Compliance Equivalent Volume (Vas)……………………………..1.17 ft.³BL
- Product (BL)………………………………………………………………..14.6 Tm
- Diaphragm Mass Inc. Airload (Mms)……………………………….40.22g
- Moving Mass Of Diaphragm (Mmd)………………………………..36.57
- Maximum Linear Excursion (Xmax)………………………………..4 mm
Materials of Construction
- Cone Material……………………………………………Paper / Kevlar
- Surround Material………………………………………Cloth
- Voice Coil Wire Material……………………………..CCA
- Voice Coil Former………………………………………Fiberglass
- Basket / Frame Material……………………………..Cast Aluminum
- Magnet Material…………………………………………Neodymium
